METSEDM6000
پاورمتر DM6000
DM6000 digital meter with basic readings - no communication
مشخصات کامل
سری
PowerLogic
range of product
device short name
DM6000
device short name
product or component type
Multimeter
product or component type
device application
Preventive maintenance
Equipment monitoring
Power monitoring
device application
type of measurement
Current
Voltage
Frequency
Power factor
Phase unbalance
Phase angle
RPM
type of measurement
[Us] rated supply voltage
44...277 V AC 50/60 Hz
44...277 V DC
[Us] rated supply voltage
network frequency
45...65 Hz
network frequency
maximum power consumption in VA
3 VA at 240 V AC
maximum power consumption in VA
display type
LED indicator
display type
sampling rate
20 samples/cycle
sampling rate
measurement current
1 A
5 A
measurement current
analogue input type
Current 0.05...6 A (impedance <= 0.1 Ohm)
analogue input type
measurement voltage
80…480 V AC phase to phase
measurement voltage
measurement accuracy
Frequency 0.1 %
Power factor 1 %
Voltage 1 % 46...277 V
Current 1 % 0.05...6 A
measurement accuracy
electromagnetic compatibility
Electrostatic discharge immunity test: , conforming to IEC 61000-4-2
Susceptibility to electromagnetic fields: , conforming to IEC 61000-4-3
Electrical fast transient/burst immunity test: , conforming to IEC 61000-4-4
1.2/50 µs shock waves immunity test: , conforming to IEC 61000-4-5
Conducted RF disturbances: , conforming to IEC 61000-4-6
Immunity to impulse waves: , conforming to IEC 61000-4-12
Conducted and radiated emissions: , A, conforming to CISPR 11
Immunity to microbreaks and voltage drops: , conforming to IEC 61000-4-11
electromagnetic compatibility
mounting mode
Flush-mounted
mounting mode
type of installation
Indoor installation
type of installation
overvoltage category
III
overvoltage category
IP degree of protection
IP40 back:
IP51 front face:
IP degree of protection
pollution degree
2
pollution degree
ambient air temperature for operation
-10…60 °C
ambient air temperature for operation
ambient air temperature for storage
-25…70 °C
ambient air temperature for storage
relative humidity
95 %
relative humidity
operating altitude
0...2000 m
operating altitude
standards
IEC 61010
UL 508
standards
product certifications
CE
product certifications
width
96 mm
width
depth
80 mm
depth
height
96 mm
height
net weight
0.4 kg
net weight
Unit Type of Package 1
PCE
Unit Type of Package 1
Number of Units in Package 1
1
Number of Units in Package 1
Package 1 Weight
543.0 g
Package 1 Weight
Package 1 Height
11 cm
Package 1 Height
Package 1 width
12.5 cm
Package 1 width
Package 1 Length
12.8 cm
Package 1 Length
Unit Type of Package 2
CAR
Unit Type of Package 2
Number of Units in Package 2
1
Number of Units in Package 2
Package 2 Weight
543.0 g
Package 2 Weight
Package 2 Height
11 cm
Package 2 Height
Package 2 width
12.5 cm
Package 2 width
Package 2 Length
13 cm
Package 2 Length
Unit Type of Package 3
S03
Unit Type of Package 3
Number of Units in Package 3
12
Number of Units in Package 3
Package 3 Weight
7.229 kg
Package 3 Weight
Package 3 Height
30 cm
Package 3 Height
Package 3 width
30 cm
Package 3 width
Package 3 Length
40 cm
Package 3 Length
Warranty
18 months
Warranty
